Oddball Enderle Buzzard

Discussion in 'Manton Push Rods Top Alcohol Tech Questions' started by brutustitan, Jun 11, 2017.

  1. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
    I just ran across this modified Buzzard Hat.
    On a 14/71 blower, it fits outside dimension wise, all except for the rear bolt holes.
    Besides longer nozzle plumbing, a custom blower restraint, and drilling and tapping the rear holes,
    would this be useable?
    Custom spacer?

    [​IMG]
    [​IMG]

    #1
  2. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
    Center to center bolt holes are 17 1/2"

    #2
  3. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
  4. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
  5. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
  6. Mike Canter

    Mike Canter Top Dragster

    Joined:
    Mar 10, 2004
    Messages:
    4,152
    Likes Received:
    73
    The opening in the top of your blower is also that big? If it is smaller then the incoming air is going to hit a real big ledge and create a lot of turbulence and reduce airflow. That is a big opening in the hat, wow

    #6
  7. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
    The blower opening is 15".
    They added 2 1/2" too the rear of the hat.
    If airflow turbulence will be a problem, then I'll
    just chop / cut it back to the original specs.
    I don't have a clue as to what their goal was for this mod.Tunnelram?

    #7
    Last edited: Jun 12, 2017
  8. Dave Koehler

    Dave Koehler Member

    Joined:
    Sep 10, 2004
    Messages:
    394
    Likes Received:
    6
    There are/were longer blowers than the 14 but I don't know the opening size. These days all the openings are moved forward and have shorter length. Betcha it came off of a tractor.

    Move it up and forward perhaps?

    #8
  9. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
    Hmmmm.....possibly.

    #9
  10. Mike Canter

    Mike Canter Top Dragster

    Joined:
    Mar 10, 2004
    Messages:
    4,152
    Likes Received:
    73
    You can fill the front of the back with that liquid plastic and shape it for flow. If you talk to DMPE or Dave Koehler they can probably tell you what the stuff is.

    #10
  11. brutustitan

    brutustitan New Member

    Joined:
    Jul 14, 2010
    Messages:
    21
    Likes Received:
    0
    It appears if I move it forward, like Dave mentionedonly a few mods would have to be done, compared to leaving it back.
