Why the holes in the blades on PSI injectors?

Discussion in 'PSI Superchargers Tech Questions' started by Lonnie Houde, May 3, 2006.

  1. Lonnie Houde

    Lonnie Houde Member

    Joined:
    Nov 14, 2005
    Messages:
    252
    Likes Received:
    0
    I noticed that alot of cars with Screw blowers, put a hole in one of their injector blades. I assume this is for more air, but why not just open up the blades a little bit? Is there another reason for it?

    #1
  2. RBS

    RBS Authorized Merchant

    Joined:
    May 6, 2004
    Messages:
    1,095
    Likes Received:
    0
    Blades

    Lonnie I Think Mostly If The Car Is Not Idling High Enough At The Starting Line Or Sounding To Rich You Can Pull A Piece Of Tape Off The Blade And Speed It Up A Little

    #2
  3. John Haley

    John Haley Alcohol Dragster

    Joined:
    May 6, 2003
    Messages:
    230
    Likes Received:
    0
    You mean like this ?




    [​IMG]

    #3
  4. TOL

    TOL Active Member

    Joined:
    May 18, 2005
    Messages:
    1,350
    Likes Received:
    17
    Why all the fixed holes in the blades, rather than a few SMC fittings drilled into the hat with removeable nibs? Sorry, just confused.....

    #4
  5. WIZBANG

    WIZBANG Member

    Joined:
    Nov 8, 2004
    Messages:
    761
    Likes Received:
    2
    I Agree With Tol ??????

    #5
  6. Eric David Bru

    Joined:
    Sep 4, 2005
    Messages:
    417
    Likes Received:
    1
  7. WIZBANG

    WIZBANG Member

    Joined:
    Nov 8, 2004
    Messages:
    761
    Likes Received:
    2
    Exactly Right !

    By The Way, Is There Anything That Jr @ Rbs Superchargers Can't Get Or Do ? That Guy Is A Great Friend To Have On Your Side !

    #7
  8. Lonnie Houde

    Lonnie Houde Member

    Joined:
    Nov 14, 2005
    Messages:
    252
    Likes Received:
    0
    John, Why exactly do people do it. To lean the motor out before staging, because lack of heat??? How is it different from a roots setup?

    #8
  9. Les Mellows

    Les Mellows New Member

    Joined:
    Jul 18, 2003
    Messages:
    319
    Likes Received:
    0
    Blade holes

    Path of least resistance for the air ? The blower vacuum will draw thru the holes, reduces the blade edges from freezing and allows for better spool control/leakage . some BV's will allow separate idle controls that do not affect the spool and visa versa .

    #9
    Last edited: May 4, 2006
  10. Dave Germain

    Dave Germain New Member

    Joined:
    Aug 1, 2003
    Messages:
    896
    Likes Received:
    0
    Icing

    the blade edges will freeze up and cause sticky throttles and the holes don't seem to ice up as much. If the motor seems a little fat on idle the crew chief can open the holes- take the tape off or pull the plastic plugs and lean it a little also.

    #10
  11. John Haley

    John Haley Alcohol Dragster

    Joined:
    May 6, 2003
    Messages:
    230
    Likes Received:
    0

    It's top secret, so i can't tell you. ;)

    #11
  12. Lonnie Houde

    Lonnie Houde Member

    Joined:
    Nov 14, 2005
    Messages:
    252
    Likes Received:
    0
    Oh!!! I see.;)

    #12
  13. Les Mellows

    Les Mellows New Member

    Joined:
    Jul 18, 2003
    Messages:
    319
    Likes Received:
    0
    I love that Secret Squirell shit , thats funny. .... of course in a way he is right secrecy is power !
    Now if you could just get that power to the ground it would be worth something .:rolleyes:

    #13
  14. M Tigges

    M Tigges TAFC

    Joined:
    Jun 11, 2003
    Messages:
    644
    Likes Received:
    1

    run a little hot does it? maybe light them smokes on top!

    did they fix your blower yet?

    #14
    Last edited: May 6, 2006
  15. nick bell

    nick bell TAFC

    Joined:
    May 12, 2003
    Messages:
    167
    Likes Received:
    0
    Thats so the mouse running the blower doesnt suffer from lack of oxygen at idle.

    #15
  16. John Haley

    John Haley Alcohol Dragster

    Joined:
    May 6, 2003
    Messages:
    230
    Likes Received:
    0

    No doesn't run too hot. It did tend to idle a little high, But i stuffed another secret squirrel in the hat too keep the other guy happy. It seems a little better. :confused:

    PSI Says my blower will ship out next week.

    #16
  17. John Haley

    John Haley Alcohol Dragster

    Joined:
    May 6, 2003
    Messages:
    230
    Likes Received:
    0
    Someone told me i got too many holes on the butterflys. I was thinking 1-2 more though and she'd run some 5.20's with the a/fuel cars. :D

    #17
  18. Les Mellows

    Les Mellows New Member

    Joined:
    Jul 18, 2003
    Messages:
    319
    Likes Received:
    0
    Yes More Holes !!

    You need more holes !! it will get the weight of the car down so you can compete with the Afuels . It should also be easier to drive you won't have to push the gas pedal at all to hit stage rpm. But to all great things there is 1 downside you may have to carry spare rotors (may have happened ??) , 'cause it will be ingesting the sponsor signage from the walls as you stage the car ........ and that will in turn Knock out 1 or both of the "Secret Squirrels":D .

    #18
  19. John Haley

    John Haley Alcohol Dragster

    Joined:
    May 6, 2003
    Messages:
    230
    Likes Received:
    0
    LOL, I knew someone would have some good advice. ;)

    #19
  20. eli

    eli Banned

    Joined:
    Dec 24, 2005
    Messages:
    1,657
    Likes Received:
    1

    I don`t know ,,,that looks like a mob hit to me!!

    #20
